The Kioxia CD8P-V Series is a mixed-use data center NVMe SSD optimized for scale-out and cloud applications including big data, IoT, online transaction processing, and virtualization. With 12.8TB capacity, PCIe 5.0 / NVMe 2.0 interface, and up to 2,000,000 IOPS random read, it delivers exceptional performance for demanding data center workloads. Equipped with power loss protection (PLP), end-to-end data correction, and 3 DWPD endurance, the CD8P-V ensures reliability and data integrity in mission-critical environments. TAA compliant and manufactured in Japan.

Characteristics

Model KCD8XPUG12T8

Hard Drive / Size 2.5\

SSD Capacity 12800 GB

Flash Type BiCS FLASH TLC

Hard Drive / Interface Type PCIE 5.0; NVMe 2.0

Max 4KB Random Read 2000000 IOPS

Max 4KB Random Write 400000 IOPS

MTBF 2500000 hours

Power / Device Type Power Supply

Power Consumption Operational 23 Watt

Power / Voltage Required 12V +/- 10%, 3.3V +/- 15%

Width 69.85 Mm

Depth 100.45 Mm

Height 15 Mm

Features Single-port design, optimized for data center class workloads

Min Operating Temperature 0 Celsius

Max Operating Temperature 73 Celsius

PerformanceMax Sequential Read 12000 MB/sMax Sequential Write:5500 MB/sEndurance:3 DWPDSpecial FeatureCOO:JAPANTAA compliance:YesUNSPSC CodeUNSPSC Code:43201830

Max Sequential Read 12000 MB/sMax Sequential Write:5500 MB/sEndurance:3 DWPD

Max Sequential Write 5500 MB/s

Endurance 3 DWPD

Special FeatureCOO JAPANTAA compliance:Yes

COO JAPANTAA compliance:Yes

TAA compliance Yes

UNSPSC CodeUNSPSC Code 43201830

UNSPSC Code 43201830

Overview

The Kioxia CD8P-V Series is a mixed-use data center NVMe SSD optimized for scale-out and cloud applications including big data, IoT, online transaction processing, and virtualization. With 12.8TB capacity, PCIe 5.0 / NVMe 2.0 interface, and up to 2,000,000 IOPS random read, it delivers exceptional performance for demanding data center workloads. Equipped with power loss protection (PLP), end-to-end data correction, and 3 DWPD endurance, the CD8P-V ensures reliability and data integrity in mission-critical environments. TAA compliant and manufactured in Japan.

Characteristics

Model KCD8XPUG12T8

Hard Drive / Size 2.5\

SSD Capacity 12800 GB

Flash Type BiCS FLASH TLC

Hard Drive / Interface Type PCIE 5.0; NVMe 2.0

Max 4KB Random Read 2000000 IOPS

Max 4KB Random Write 400000 IOPS

MTBF 2500000 hours

Power / Device Type Power Supply

Power Consumption Operational 23 Watt

Power / Voltage Required 12V +/- 10%, 3.3V +/- 15%

Width 69.85 Mm

Depth 100.45 Mm

Height 15 Mm

Features Single-port design, optimized for data center class workloads

Min Operating Temperature 0 Celsius

Max Operating Temperature 73 Celsius

PerformanceMax Sequential Read 12000 MB/sMax Sequential Write:5500 MB/sEndurance:3 DWPDSpecial FeatureCOO:JAPANTAA compliance:YesUNSPSC CodeUNSPSC Code:43201830

Max Sequential Read 12000 MB/sMax Sequential Write:5500 MB/sEndurance:3 DWPD

Max Sequential Write 5500 MB/s

Endurance 3 DWPD

Special FeatureCOO JAPANTAA compliance:Yes

COO JAPANTAA compliance:Yes

TAA compliance Yes

UNSPSC CodeUNSPSC Code 43201830

UNSPSC Code 43201830

KIOXIA AMERICA, INC. by KIOXIA AMERICA, INC.

Kioxia CD8P-V 12.8TB PCIe 5.0 NVMe U.2 Enterprise SSD

Mfr #: SDF7481GEB01T

Regular price: $8,719.07
Sale price: $8,719.07
Regular price: ~~$9,529.04~~

FREE Delivery on Orders $3,000+

* NO SALES TAX Except in CA

** Prices and stock might change without notice due to high market volatility.

The Kioxia CD8P-V Series KCD8XPUG12T8 is a 12.8TB mixed-use data center NVMe SSD built on PCIe 5.0 and NVMe 2.0. Featuring BiCS ... Read more

The Kioxia CD8P-V Series KCD8XPUG12T8 is a 12.8TB mixed-use data center NVMe SSD built on PCIe 5.0 and NVMe 2.0. Featuring BiCS FLASH TLC memory, 3 DWPD endurance, and up to 12,000 MB/s sequential read, it's optimized for cloud, big data, OLTP, and virtualization workloads in high-density deployments.

Condition: NEW
